Briggs and Stratton 1726829SM Relay - Single Pole Double Throw

Product Overview

The Briggs and Stratton 1726829SM is a genuine OEM replacement relay featuring a single pole double throw (SPDT) configuration. Designed for uses in a variety of Briggs & Stratton engines and equipment, it delivers consistent electrical switching performance. SPDT relays are essential components that control electrical circuits by switching between two output terminals. They are commonly employed in applications such as lawn mowers, generators, and other small engines where reliable switching is required. This relay is manufactured to exacting specifications to ensure direct compatibility and long service life.

What Makes Key Features Important?

• Genuine OEM Briggs & Stratton replacement part
• Single pole double throw (SPDT) contacts
• OEM quality for direct fit and reliable operation
• Part number 1726829SM
• Compact design for easy installation in confined spaces

Technical Specifications

• Type: Relay
• Contact Configuration: Single Pole Double Throw
• Part Number: 1726829SM
• OEM: Yes
• Operating Voltage: Typically 12V DC (verify with equipment manual)
• Contact Material: Silver alloy for high conductivity and durability

Installation Guide

Installation should be carried out by a qualified technician. Disconnect the power supply before servicing. Ensure the relay is sely mounted and all connections are tightened properly. Identify the centre terminal of the relay; it is common to both throw positions. The wires are labelled with colour codes for easy identification. Organise the wiring according to the equipment's wiring diagram to avoid cross-connections. After installation, test the circuit to verify proper operation.

Compatibility

This relay is designed as a direct replacement for the original part in Briggs & Stratton equipment. Common applications include lawn mowers, generators, pressure washers, and other small engine machines. Always check your equipment's parts manual to confirm that part number 1726829SM is listed as the correct relay for your specific model. If you are unsure, consult the manufacturer's website or an authorised dealer.

Safety Information

Before beginning any work, disconnect the battery and remove any power sources to prevent accidental start-up. Wear appropriate personal protective equipment, such as safety glasses and gloves. Do not attempt to install or service electrical components unless you are trained and qualified. Relay failure can cause equipment malfunction; always uses genuine OEM parts for replacements.

Maintenance

Periodically inspect the relay for signs of corrosion, loose connections, or physical damage. Clean the contacts with a suitable electrical contact cleaner if needed. Check that all mounting screws are tight. Operate the relay through its switching cycles to ensure smooth operation. If any abnormalities are detected, replace the relay immediately.

Frequently Asked Questions

Is this relay compatible with my equipment?

Check your equipment's parts manual for part number 1726829SM. This relay is a direct replacement for the original part.

What is the warranty?

This part is covered by Briggs & Stratton's standard warranty. Refer to the manufacturer's warranty policy for details.

How do I test the relay?

Uses a multimeter to check continuity between terminals. With no voltage applied, the common terminal should be connected to one of the throw terminals. When voltage is applied, it switches to the other throw terminal. Refer to the SPDT wiring diagram for your specific application.

Warranty and Support

This genuine OEM part is backed by Briggs & Stratton's warranty. For support, contact the manufacturer or consult the resources available on their official website.
